Features
- Low air pressure and air consumption for less paint rebound and strong adhesion. Reduce environmental pollution.
- Balanced design with ergonomics for better grip and less user hand fatigue.
- Precision machined gun body, fluid nozzle, fluid needle and air cap. Durability.
- Superior atomization and uniform pattern.
Specification
| Model | Type of Feed |
Nozzle Orifice Ømm(in) |
Air Cap |
Atomizing Air pressure Mpa(bar) |
Fluid Output Ml/min |
Air consumption l/min(cfm) |
Pattern Width mm(in) |
Weight g(lbs) |
| X-102L-1S |
Pressure |
1.2 (0.047) |
LV4 |
0.2 (2.0) | 60 | 200 (7.0) |
170 (6.7) |
325 (0.71) |
| X-102L-1S |
Pressure |
1.4 (0.055) |
LV4 |
0.2 (2.0) | 80 | 200 (7.0) |
180(7.1) | 325 (0.71) |
| X-102L-1S |
Pressure |
1.6 (0.063) |
LV4 |
0.2 (2.0) | 95 | 200 (7.0) |
190(7.5) |
325 (0.71) |
| X-102L-1G |
Gravity |
1.2 (0.047) | LV4 |
0.1 (1.0) | 80 | 200 (7.0) |
200(7.9) | 325 (0.71) |
| X-102L-1G | Gravity | 1.4 (0.055) | LV4 | 0.1 (1.0) | 130 | 200 (7.0) | 220(8.7) | 325 (0.71) |
| X-102L16G | Gravity | 1.6 (0.063) | LV4 | 0.13 (1.3) | 100 | 240 (8.4) | 220(8.7) | 325 (0.71) |
| X-102L18G | Gravity | 1.8 (0.071) | LV4 | 0.13 (1.3) | 120 | 240 (8.4) | 210(8.3) | 325 (0.71) |
- X-102 Spray Distance: 200mm
- Paint viscosity: 16sec/Ford#4
- Fluid connector: 1/4PF; Air connector: 1/4PF
- Cup and container is available.
