Specification
| Model | Type of Feed | Nozzle orifice Ø mm (in) | Air Cap |
Atomizing Air Pressure Mpa (bar) |
Fluid Output ml/min | Air consumption l/min(cfm) | Pattern Width mm (in) |
Weight g(lbs) |
| XA-11S-P06 | Pressure | 0.6(0.024) | S4 |
0.15(1.5) | 30 | 80(2.8) | 80(3.1) | 385(0.82) |
| XA-11S-P08 | Pressure | 0.8(0.031) | S4 | 0.15(1.5) | 45 | 80(2.8) | 100(3.9) | 385(0.82) |
| XA-11S-P12 | Pressure | 1.2(0.047) | S4 | 0.15(1.5) | 75 | 80(2.8) | 140(5.5) | 385(0.82) |
