Specification
| HVLP Model |
Type of Feed |
Nozzle Orifice Ømm(in) |
Air cap |
Air Pressure |
Material Pressure |
Air pressure of gun lnlet psi(bar) |
Air pressure of Air cap psi(bar) | Weight g(lbs) |
| X-3-03P |
Pressure |
0.3(0.011) |
X45 X60 X90 |
Max. 6 bar |
Max. 4bar |
8~25 (0.5~5) |
5~20 (0.35~1.4)) | 240 (0.53) |
| X-3-05P |
Pressure | 0.5(0.019) |
X45 X60 X90 |
Max. 6 bar |
Max. 4bar |
8~25 (0.5~5) |
5~20 (0.35~1.4)) | 240 (0.53) |
| X-3-08P |
Pressure |
0.8(0.031) |
X45 X60 X90 |
Max. 6 bar |
Max. 4bar |
8~25 (0.5~5) |
5~20 (0.35~1.4)) | 240 (0.53) |
| X-3-10P |
Pressure |
1.0(0.039) |
X45 X60 X90 |
Max. 6 bar |
Max. 4bar |
8~25 (0.5~5) |
5~20 (0.35~1.4)) | 240 (0.53) |
