Features
- Application: Various case (Computer/Mobile), Funiture, Glass, Pressing, Hardware.
- XER-22 Spray Distance: 200~250mm / Fluid connector: 1/8PF; Air/CYL connector: 1/8PF.
- Paint viscosity: 16sec/Ford #4
Specification
| Products Model | Type of Feed | Nozzle orifice Ø mm (in) | Air Cap |
Atomizing Air pressure Mpa (bar/psi) CAP |
Atomizing Air pressure Mpa (bar/psi) FAN | Fluid Output ml/min | Air consumption l/min(cfm) | Pattern Width mm(in) | Weight g(lbs) |
| XER-22-08P | Pressure | 0.8(0.031) | HP2 | 0.22(2.2/31) |
0.24(2.4/34) | 400 | 500(17.7) | 240(9.4) | 365(0.80) |
| XER-22-10P | Pressure | 1.0(0.039) | HP2 | 0.22(2.2/31) | 0.24(2.4/34) | 450 | 500(17.7) | 270(10.6) | 365(0.80) |
| XER-22-12P | Pressure | 1.2(0.047) | HP2 | 0.22(2.2/31) | 0.24(2.4/34) | 500 | 500(17.7) | 300(11.8) | 365(0.80) |
