Features
- Balanced design with ergonomics for better grip and less user hand fatigue.
- Precision machined gun body, fluid nozzle, fluid needle and air cap. Durability.
- Superior atomization and uniform pattern.
- High transfer efficiency, fast working speed.
Specification
| Model | Type of Feed |
Nozzle Orifice Ømm(in) |
Air Cap |
Atomizing Air pressure Mpa(bar) |
Fluid Output Ml/min |
Air consumption l/min(cfm) |
Pattern Width mm(in) |
Weight g(lbs) |
| X-402-12G | Central Gravity |
1.2 (0.047) |
LV2 |
0.29 (3.0) |
160 | 370(13.1) |
250(9.8) |
370 (0.81) |
| X-402-13G |
Central Gravity |
1.3 (0.051) |
LV2 |
0.29 (3.0) |
200 | 370(13.1) |
300 (11.8) | 370 (0.81) |
| X-402-14G | Central Gravity | 1.4 (0.055) | LV2 | 0.29 (3.0) | 265 | 370(13.1) | 320(12.6) | 370 (0.81) |
| X-402-16G | Central Gravity | 1.6 (0.063) | LV2 | 0.29 (3.0) | 310 | 370(13.1) | 340 (13.4) | 370 (0.81) |
| X-402-18G | Central Gravity | 1.8 (0.071) | LV1 | 0.29 (3.0) | 400 | 380(13.4) | 320(12.6) | 370 (0.81) |
| X-402-25G | Central Gravity | 2.5 (0.098) | W1 | 0.29 (3.0) | 580 | 360(12.7) | 340(13.4) | 370 (0.81) |
- X-402 Spray Distance: 250mm
- Paint viscosity: 16sec/Ford#4
- Fluid connector: M16x1.5 ; Air connector: 1/4PF
